NBF-32022 by Bud Industries Weatherproof Enclosure

Product Overview

The NBF-32022 is a great option to mount controllers and other peripherals in a water resistant box. We carry a mounting plate that will work with both Falcon and Kulp style controllers while housing up to three power supplies.

Want some help building a full controller? Check out our Build-A-Kit page for controllers. It will assist you in finding all the items you need for a full controller buildout https://www.wiredwatts.com/build-a-controller-kit

Product Specifications

• External Dimensions: 13.78" × 9.84" × 5.91"
• Internal Dimensions: 12.82" × 8.88" × 5.32"
• Weight: 3 lbs
• Color: Light Gray
• Indoor / Outdoor: Indoor (Not UV Stabilized)
• Flammability Rating: UL94-HB
• Type of Plastic: ABS
• Service Temperature Min: -40°C
• Service Temperature Max: 60°C
• IP Rating: 66

Additional Documents

• Bud-NBF-32022-Hole-Drilling-Pattern-v1.pdf
• Bud-NBF-32022-Hole-Drilling-Pattern-v2.pdf
